Features. 365-day programming. Two Occupied and two Not Occupied periods per day.
Thermostat Interface Module (TIM) connections to thermostat from PDA for advanced configuration, programming, keypad lockout, etc. Individual heat and cool setpoints available for Occupied and Not Occupied periods. P+I+D control minimizes temperature fluctuations. Recovery ramping control automatically optimizes equipment start times based on building load. Universal Versaguard™ Thermostat guards available. Convenient overrides allow temporary setpoint changes. Keypad multi-level lockout available with all models.
Remote sensor capability - EXCEPT T7350A model - for temperature (including outdoor air and discharge air) and humidity sensors. Auxiliary contact interfaces with a Honeywell Economizer System (for total rooftop control integration) or as a dehumidification output.
The Honeywell T7350 Commercial Programmable Thermostat controls 24 VAC single zone heating, ventilating and air conditioning (HVAC) equipment. The T7350 consists of a thermostat and a subbase. The thermostat includes the keypad and display for 7-day programming and the subbase includes equipment control connections. T7350M models have 2 modulating outputs for heat and/or cool, and the T7350H models have LonWorks® capability. The W7350 WebStat is a web-based building manager that allows contractors and facility managers to view and command T7350H Commercial Programmable Thermostats.
It communicates over the LonWorks® network to perform building management control of the T7350H thermostats through a web browser. It runs building management applications such as trending, scheduling and alarming. The WebStat Bundle (W7350A1000) includes the WebStat controller, a LON® card, and a power supply.
(Wholesale customers, for your special pricing) Qty Model Description In Stock List Price Internet Price T7350A1004 1H/1C STD OR 2H/1C HP STAT 609.00 487.20 T7350B1002 2H/2C STD OR 3H/2C HP STAT 751.00 600.80 T7350D1008 3H/3C STD OR 2H/4C HP W/RH 868.00 694.40 T7350H1009 LON, HP OR CONV. T-STAT, PROGRAMMABLE 1,161.00 928.80 T7350H1017 LON/2MOD & 2 RELAY STD W/RH 1,214.00 971.20 T7350M1008 2MOD & 2 RELAY STD W/RH 1,014.00 811.20 USB-TIM/U USB THERMOSTAT INTERFACE MODULE CABLE 432.00 345.60 W7350A1000 WEBSTAT CONTROLLER 3,502.00 2,801.60 Y7355H1009 T771A1005/C7041B2013 SENSOR COMBO 1,672.00 1,337.60. Supply Voltage:20 to 30 Vac @ 5 VA, 50/60 Hz, W7350: 100 to 240 Vac, 47 to 63 Hz, 0.5A Accuracy: ±1℉(±1℃). Conttact Rating:Running: 1.5A maximum.
Inrush: 7.5A maximum. Setpoint Range:Heating: 40℉ to 90℉ (4℃to 32℃).
Cooling: 45℉ to 99℉ (7℃ to 37℃). Deadband: ℉ (1℃). Additional Specifications:Finish (color): Trident White. Battery:No batteries required Battery Backup:W7350: 5 minutes typical; shutdown begins within 10 seconds Clock Accuracy:±1 min./month (30 days).
Communication Interface:W7350: Ethernet: Two ports; One unused; 10/100 Mbps; RJ-45 connectors, Communication Card: 78 Kbps FTT10 A LON® Adapter and LonWorks® communication driver, Unused: two communication ports (RS-485 and RS-232) Electrical Life:W7350: NPB-WPM-US wall plug power supply, Class-A device Input:Temperature: 20K ohms. Humidity: 0-10 Vdc. Outdoor: 3000 PTC. Discharge Air: 20K ohms. Mutoh valuejet service manual.
Honeywell Thermostat T7350m1008 Manual
Occupancy Sensor: Dry contact switching 30 Vdc at 1 mA. Memory:W7350: 64 MB SDRAM and Serial Flash Model:See Table 1 Modulation:4 to 20 mA with 510 ohm maximum terminating resistance. Operate Time:Minimum On Heat: 1 minutes. Cool: 3 minutes.
Minimum Off (Cool and Heat Pump): 1 minute. Conttact Rating:Running: 1.5A maximum. Inrush: 7.5A maximum. Throttling Range:Automatically adjusts based on heat/cool stages. Manually adjustable with TStatSpec software or PDA. Operating Temperature:30℉ to 110℉ (-1℃ to 43℃)., W7350: 32 to 122 ℉ (0 to 50 ℃) Operating Humidity: 5% to 90% RH, noncondensing., W7350: 5% to 95% RH, Non-condensing Mounting:Mounts on subbase., W7350: DIN rail or screw Enclosure Rating:W7350: Plastic chasis and cover Dimensions:See Fig 1, W7350: 6.3″(160mm) Width x 4.8″ (122mm) Height (including connectors) x 2.4″ (61mm) Depth Weight:1.24 lb.
(0.57 Kg) Approvals:CE, NEC Class 2. FCC Part 15 subpart J Class A, RF Emissions FCC part 15, CE, Class A, C-tick Warranty:1 year.
